Complete Elevator System Plans and Designs. MRL Type L

Get the full digital bundle and Solidworks files for a complete Elevator System MRL Type L, ready for manufacturing. This bundle will cut down thousands of Euros/USD from your design and planning phase, and set you up with ready to manufacture plans from design to engineering files, all in accordance with 81.20/81.21 and 81.1/81.2 standards.

All plans and designs were meticulously prepared to include easy to source parts, contemporary and clever design, fewer components than the rest of the market (metal parts, screws). They were prepared to allow for manufacturability but also for easy assembly, disassembly and transport, under a bolted construction concept without the need for special construction knowledge or welding required. They will not only help you hit the market running but also ease your clients' work and reduce their expenses.

The bundle includes complete sets of:

• CAD Drawings: 2D and 3D models (.edrw, .pdf), 3D renders (.png)
• Solidworks Files: Parts(.SLDPRT), Assemblies(.SLDASM), Drawings(.SLDDRW)
• Production files: Bill of Materials (.easm), Laser cutting, punching & CNC bending (.step, .dxf)

For the following subsystems:

• Elevator Cabin (Cabin Inox, Apron Standard)
• Automatic Landing / Cabin Door (2 Panel, Telescopic 800)
• Machine Room Less (MRL)
• Machine Room Controllers MRL (Cabin Frame, Revizion Frame)
• Balustrade Full (Standard, Folding, Telescopic)
• Cabin Operating Panel - COP (Surface Mounted)
• Landing Operating Panel - LOP (Flat, Mounted)
